Specifications

ACCOMODATION 12 GUESTS + 7 CREW

LENGTH OVERALL 40.20 meters - 131 ft

LENGTH  35.10 meters    - 115 ft

BEAM MAX   8.60 meters - 28 ft

DRAUHT   2 meters - 6.5 ft

​DISPLACEMENT (Light Ship) 190 Tonnes

DISPLACEMENT (Fully loaded) 235 Tonnes

GROSS TONNAGE 395 GT

SPEED 17 Knots

MAIN ENGINES 2 x CAT C32 1900HP @ 2300 Rpm

GEARBOX TWIN DISC MGX-6598DC    3.03:1

ENGINE CONTROL GLENDINING ( 1 main + 2 Wing  station)

GENERATORS CAT C4.4 75KW

CAT C4.4 75KW

SHAFT PROPELLER CJR (UK)  4,5” MARINEMET 25 Shaft  / 5 Blades Class S Propellers

115 / 208 VAC 3P 60Hz   Main Service

ASEA 75 kVA Shore Power Converter

24VDC Service and Engine Start System

Service Batteries 2200 Ah ( 2x 100 A Charger )

Emergency Batteries 880 Ah ( 1x 80 A Charger )

Radio Batteries 260 Ah ( 1x 30 A Charger )

ME & Generator Batteries  (x2) 960 Ah ( 2x 40 A Charger )

Fire Puımp Batteries 880 Ah ( 1x 80 A Charger )

Diesel Oil : 30.250 Lt / 8.000 Gallons
Fresh Water : 4.540 Lt / 1.200 Gallons
Black Water : 2.000 Lt / 500 Gallons
GreyWater : 3.000 Lt / 800 Gallons

HULL / SUPERSTRUCTURE : CARBON RAINFORCED E-GLASS - EPOXY COMPOSITE SANDWICH

OPEN DECK : HANDLAID BURMESE / MYANMAR TEAK OR NON SKID PAINT

PAINT SYSTEM : AWLGRIP
